Energy Storage

–Solar-Wind Power System / City Grid (On/Off) / Community and Family
Back-up System and UPS
–Telcom Base / CATV system / Computer Server Center / Medical Instrument / Military Equipment
Other Applications
–Security and Electronics / Mobile POS, Mining Light / Torch / LED Light / Emergency Light
–RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard
–LED Backup / Engine Starting Battery, etc.

PRODUCT PARAMETER

Specification
No.	Item	General Parameter	Remark
1	Combination method	16S8P
2	Rated Capacity	400Ah	Standard discharge after Standard charge(package)
3	Factory Voltage	51.2V	Mean Operation Voltage
4	Voltage at end of Discharge	46V	Mean Operation Voltage
5	Charging Voltage	58.4V
6	Internal Impedance	≤40mΩ	Internal resistance measured at AC 1KH Z after 50% charge The measure must uses the new batteries that within one week after shipment and cycles less than 5 times
7	Standard charge	Constant Current 100A	Charge time : Approx 4.5h
	Maximum Charge	250A
8	Standard discharge	Constant current:100A
9	Maximum Continuous Discharge Current	250A
10	Maximum Discharge Current	40A
11	Operation Temperature Range	Charge: 0~45℃	60±25%R.H.Bare Cell
		Discharge: -20~55℃
12	Storage Temperature Range	Less than 12 months : -10~35℃	60±25%R.H.at the shipment state
		Less than 3 months: -10~45℃
		Less than 7 day : -20~65℃
13	Dimensions	(L*W*H) 820*460*700mm	Include case
14	Weight	250kg	Include case



Good Quality Packs

VS

Low Quality Packs

◆ Experience–More than 12 years Specialized in lithium battery, Leaders of Lithium Lifepo4 Battery.
◆ Certification–CE,UL,MSDS,Test Report from National Center For Quality Supervision and Inspection of Battery Products approved.
◆ Quality Control– 37 production process,7 steps quality check to promise stable quality and high reliability for you.
◆ Best Material– Insist on choosing top quality cell, material and accessories, lithium battery last longer time.
◆ Fresh battery– All battery is fresh Production.
