BS – 48300/OGM15000U

——————–

NOMINAL VOLTAGE            – 51.2V (16 CELLS)

RATED CAPACITY             – 300Ah

RATED ENERGY               – 15.36KWh

SIZE (W x H x D)           – 810.00 x 640.00 x 185.00mm

WEIGHT                     – 125Kgs

CHARGE LIMIT VOLTAGE       – 57.6V

DISCHARGE LIMIT VOLTAGE    – 43.2V

STANDARD CHARGE CURRENT    – 20A

MAXIMUM CHARGE CURRENT     – 100A

STANDARD DISCHARGE CURRENT – 50A

MAXIMUM DISCHARGE CURRENT  – 100A

OPERATION TEMPERATURE      – 0 – 45 Celsius

BMS FUNCTION :

————-

Battery management system (BMS built in, Voltage and current protection for Over-Charge

and discharge, support CAN RS 485, RS 232 COMMUNICATION, History Records.

INVERTER COMPATIBILITY :

————————

Compatible with all Major Inverters including but not limited to :

VICTRON, DEYE, GROWATT, GSL, OGM, etc
