12KVA KM Smart Hybrid inverter

12KVA KM Smart Hybrid Inverter

12KVA KM Smart Hybrid Inverter

PSC SOLAR(UK) KM SMART HYBRID SOLAR INVERTER.

12KVA KM Smart Hybrid inverter

12KVA KM Smart Hybrid Inverter

12KVA KM Smart Hybrid Inverter

PSC SOLAR(UK) KM SMART HYBRID SOLAR INVERTER.

12KVA (11KW)/48V PSC SOLAR(UK) /KM GRID TIED SMART HYBRID SOLAR INVERTER

Original price was: ₦1,575,350.Current price is: ₦1,155,350.

Product code: PSC 11K-KM-EU

Weight: 19.kg

Dimensions: 146.00mm x 312.00mm x 495.00mm

(WORKS WITH/WITHOUT BATTERIES)

Category: INVERTERS

Description
TECHNICAL SPECIFICATIONS/MANUAL

FEATURES :

◆ High Frequency off grid hybrid solar inverter SUB-D 3-11KW ,PF=1

◆ 3 in 1 design, Power Inverter + MPPT controller + Grid Charger

◆ Working without battery during daytime

◆ Support lithium activation wake-up and cold start function

◆ Auto restart while AC is recovering

◆ Intelligent power supply mode, intelligent Distribution of solar panel/mains/battery power shares

◆ AC and PV charge voltage adjustable, meet different types battery charge requirements

◆ Adjustable Charge Current & Voltage, selectable Lead acid / Lithium battery

◆ Solar, Grid and Battery Energy complement each other, priority selectable

◆ RS232, BMS/RS485,Dry Contact Communication

◆ Wi-Fi Plug or GPRS option for Mobile App, Automatic generator starting option

◆ Economical model optional for 3KW , small capacity MPPT and PV input

◆ 6.2KW/11KW Grid tie and parallel function option , max 9 units

◆ Wide MPPT range 40–500VDC/120-500VDC, 60A/100A/150A for different modes

◆ Intelligent 3 stage AC battery charger, 60/80A/150A for different modes

◆ Selectable Utility, Solar or Battery priority, power Saver Modes

◆ Pure sine wave output, suitable for different loads

◆ Protection for overload, over temperature, short-circuit, battery Low, battery reverse connection
